¡ó Product description
Applications and installation
Centrifugal pumps with single impeller are able to offer high flow rates, provide smooth, nonpulsating delivery, and regulate the flow rate over a wide range without damaging the pump.
For the correct functioning of the pump, use clean water, or non-aggressive liquids charged with small solid impurities.
To be used in flow irrigation system in gardening, agriculture and industrial fittings.
Pumps should be installed in a covered area, protected against the weather.
Operating limitations
Max ambient temperature up to 40¡æ
Max fluid temperature up to 80¡æ
Max pressure up to 10 bar
Construction features
PUMP
Pump Body: Cast Iron
Impeller: Brass
Mechanical Seal: Carbon / Ceramic / Stainless Steel
MOTOR
Single Phase
Heavy Duty Continuous Work
Motor Housing: Aluminum
Shaft: Carbon Steel / Stainless Steel
Insulation: Class B / Class F
Protection: IP44 / IP54
Cooling: External Ventilation
