¡ó Product description
Applications and installation
The HF series pumps are specifically designed to achieve high delivery rates with low to medium heads for industrial and agricultural uses. Their volute impeller makes it able to pump water that is even fairly dirty. High delivery rates under continuous or heavy duty, making them advantageous for rain and gravity irrigation, for pumping water from lakes, river, well and for a wide variety of other applications, etc..
Pumps should be installed in a covered area, protected
against the weather.
Operating limitations
Max ambient temperature up to 40¡æ
Max fluid temperature up to 80¡æ
Max pressure up to 10 bar
Construction features
Pump Body: cast iron
Motor Housing: aluminum
Shaft:45# steel /stainless steel
Impeller: Brass
Motor: closed, externally ventilated
Insulation Class: B/F
Protection Class: IP44 /IP54
Duty: continuously rated
Mechanical Seal: ceramic steatite/ metalized carbon
