¡ó Product description
Applications and installation
The Automatic booster system consists of a water pump, an airtight pressure tank, and a pressure switch. The specially designed structure make it better appearance and performance. The pressure tank with a non-toxic rubber membrane, or called pressure vessel, has been pre-filled with air pressure of about 0.12 Mpa before leaving the factory. These systems give suitable mains water pressure as required by modern domestic appliances and industrial applications, and will ensure enough water to supply all user outlets.
Pumps should be installed in a covered area, protected against the weather.
Operating limitations
Liquid temperature up to 60¡æ
Ambient temperature up to 40¡æ
Total suction lift up to 9m
Continuous duty
Construction features
PUMP
Pump Body: Cast Iron / Cast Iron with brass insert
Impeller: Brass / Plastic with brass insert
Mechanical Seal: Carbon / Ceramic / Stainless Steel
MOTOR
Single Phase
Heavy Duty Continuous Work
Motor Housing: Steel-plate
Shaft: Carbon Steel / Stainless Steel
Insulation: Class B / Class F
Protection: IP44 / IP54
Cooling: External Ventilation
