¡ó Product description
Applications and installation
AUTOSW110 is a self-suctionl pump which is specially designed for household use. It has the advantage of beautiful design, low noise , easy operate. It is widely used for pumping clean water from tank, pool etc.
Pumps should be installed in a covered area, protected against the weather.
Operating limitations
Max ambient temperature up to 40¡æ
Max fluid temperature up to 80¡æ
Max pressure up to 10 bar
Construction features
Pump Body: cast iron
Motor Housing: cast iron
Shaft: 45# steel /stainless steel
Impeller: Brass
Motor: closed, externally ventilated
Insulation Class: B/F
Protection Class: IP44/IP54
Duty: continuously rated
Mechanical Seal: ceramic steatite/ m
